Mahr MarCal 16 EWR-V Digital Universal Caliper

FEATURES

High contrast analog display
Locking screw above
Lapped guideway
Measuring blade for inside measurements
Slide and beam made of hardened stainless steel
Step measuring function
Immediate measurements due to the Reference System
Raised guideway for the protection of the scale
Excellent resistance against dust, coolants and lubricants
Dirt wipers are integrated in the slide
SoftwareMarCom Professional free download: www.mahr.com/marcom (only for Mahr data cables and wireless systems with USB and RS232 interface)
Digit height : 8.5 mm
Data interface : USB, Opto RS232C, Digimatic, wireless
Energy supply : Battery life approx. 3 years
IP protection category : IP 67
Package contains : battery, instruction manual, case, Setting gage for inside measurement 16 Eel, measuring force device 16 Ec, depth measuring bridge 16 Em, anvils for outside measurement 16 Eea 1– 3, anvils for inside measurement 16Eei 1– 3, 4118808 without measuring anvils, adjustment bridge and measuring force equipment

รหัสสินค้า: TMA-24 หมวดหมู่: Dimension, สินค้า

Download: Mahr MarCal 16 EWR-V Data Sheet

FUNCTIONS

TECHNICAL DATA

Order no.	Type	Measuring range Measuring range inch		Numerical increment	Error limit Error limit inches (text)		Standard	Depth rod Incl. accessories
mm			inch	mm/inch	mm	inch
4118807	16 EWR-V	0 – 200	0 – 8”	0.01 / .0005”	0.03	.001”	DIN 862	rectangular	•

ยี่ห้อ	Mahr
