Mahr MarCal 16 EWR Digital Caliper

FEATURES

High contrast analog display
Locking screw above
Lapped guideway
Measuring blade for inside measurements
Slide and beam made of hardened stainless steel
Step measuring function
Immediate measurements due to the Reference System
Raised guideway for the protection of the scale
Excellent resistance against dust, coolants and lubricants
Dirt wipers are integrated in the slide
SoftwareMarCom Professional free download: www.mahr.com/marcom (only for Mahr data cables and wireless systems with USB and RS232 interface)
Digit height : 8.5 mm
Data interface : USB, Opto RS232C, Digimatic
Energy supply : Battery life approx. 3 years
IP protection category : IP 67
Package contains : battery, instruction manual, case

SKU: TMA-16 Categories: Dimension, Products

Download: Mahr MarCal 16 EWR Data Sheet

FUNCTIONS

TECHNICAL DATA

Order no.	Type	Measuring range Measuring range inch		Numerical increment	Error limit Error limit inches (text)		Standard Depth rod		Friction wheel
mm			inch	mm/inch	mm	inch
4103064	16 EWR	0 –150	0 –6”	0.01 / .0005”	0.03	.001”	DIN 862	round
4103065	16 EWR	0 –150	0 –6”	0.01 / .0005”	0.03	.001”	DIN 862	round	•
4103066	16 EWR	0 –150	0 –6”	0.01 / .0005”	0.03	.001”	DIN 862	rectangular
4103067	16 EWR	0 –150	0 –6”	0.01 / .0005”	0.03	.001”	DIN 862	rectangular	•
4103068	16 EWR	0 –200	0 –8”	0.01 / .0005”	0.03	.001”	DIN 862	rectangular
4103069	16 EWR	0 –200	0 –8”	0.01 / .0005”	0.03	.001”	DIN 862	rectangular	•
4103070	16 EWR	0 –300	0 –12”	0.01 / .0005”	0.04	.0015”	Factory standard
4103071	16 EWR	0 –300	0 –12”	0.01 / .0005”	0.04	.0015”	Factory standard		•

Brand	Mahr
